Description:
| Manufacturer | Taiyo Yuden | Manufacturer's Part # | NRS6028T150MMGJ |
|---|---|---|---|
| Categories | Inductors, Coils, Chokes | Sub-Categories | Fixed Inductors |
| Series | NR, S Type | Part Status | Active |
| Type | Wirewound | Material - Core | Ferrite |
| Inductance | 15µH | Tolerance | ±20% |
| Current Rating | 1.8A | Current - Saturation | 1.6A |
| Shielding | Shielded | DC Resistance (DCR) | 123.5 mOhm Max |
| Q @ Freq | - | Frequency - Self Resonant | 17MHz |
| Ratings | - | Operating Temperature | -25°C ~ 125°C |
| Inductance Frequency - Test | 100kHz | Features | - |
| Mounting Type | Surface Mount | Package / Case | Nonstandard |
| Supplier Device Package | - | Size / Dimension | 0.236" L x 0.236" W (6.00mm x 6.00mm) |
| Height - Seated (Max) | 0.110" (2.80mm) |
