Description:
| Manufacturer | Silicon Labs | Manufacturer's Part # | SI8621BC-B-IS |
|---|---|---|---|
| Categories | Isolators | Sub-Categories | Digital Isolators |
| Series | - | Part Status | Active |
| Technology | Capacitive Coupling | Type | General Purpose |
| Isolated Power | No | Number of Channels | 2 |
| Inputs - Side 1/Side 2 | 1/1 | Channel Type | Unidirectional |
| Voltage - Isolation | 3750Vrms | Common Mode Transient Immunity (Min) | 35kV/µs |
| Data Rate | 150Mbps | Propagation Delay tpLH / tpHL (Max) | 13ns, 13ns |
| Pulse Width Distortion (Max) | 4.5ns | Rise / Fall Time (Typ) | 2.5ns, 2.5ns |
| Voltage - Supply | 2.5V ~ 5.5V | Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Surface Mount | Package / Case | 8-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 8-SOIC |
