Description:
| Manufacturer | Littelfuse | Manufacturer's Part # | LVR016K-2 |
|---|---|---|---|
| Categories | Circuit Protection | Sub-Categories | PTC Resettable Fuses |
| Series | PolySwitch®, LVR | Part Status | Active |
| Type | Polymeric | Voltage - Max | 240V (265V Int) |
| Current - Max | 2A | Current - Hold (Ih) (Max) | 160mA |
| Current - Trip (It) | 370mA | Time to Trip | 15s |
| Resistance - Initial (Ri) (Min) | 2.5 Ohms | Resistance - Post Trip (R1) (Max) | 7.8 Ohms |
| Resistance - 25°C (Typ) | - | Operating Temperature | -20°C ~ 85°C |
| Ratings | - | Mounting Type | Through Hole |
| Package / Case | Radial, Disc | Size / Dimension | 0.390" Dia x 0.150" T (9.90mm x 3.80mm) |
| Height - Seated (Max) | 0.543" (13.80mm) | Thickness (Max) | - |
| Lead Spacing | 0.200" (5.08mm) |
