Description:
| Manufacturer | KEMET | Manufacturer's Part # | A700D107M006ATE015 |
|---|---|---|---|
| Categories | Capacitors | Sub-Categories | Aluminum - Polymer Capacitors |
| Series | AO-Cap A700 | Part Status | Active |
| Type | Polymer | Capacitance | 100µF |
| Tolerance | ±20% | Voltage - Rated | 6.3V |
| ESR (Equivalent Series Resistance) | 15 mOhm | Lifetime @ Temp. | - |
| Operating Temperature | -55°C ~ 125°C | Ratings | - |
| Applications | General Purpose | Ripple Current @ Low Frequency | - |
| Ripple Current @ High Frequency | 4.1A @ 100kHz | Impedance | - |
| Lead Spacing | - | Size / Dimension | 0.287" L x 0.169" W (7.30mm x 4.30mm) |
| Height - Seated (Max) | 0.122" (3.10mm) | Surface Mount Land Size | 0.287" L x 0.169" W (7.30mm x 4.30mm) |
| Mounting Type | Surface Mount | Package / Case | 2917 (7343 Metric) |
