Description:
| Manufacturer | Shenzhen JDT Fuse | Manufacturer's Part # | ASMD0805-075 |
|---|---|---|---|
| Categories | Circuit Protection | Sub-Categories | PTC Resettable Fuses |
| Series | Material Type | - | |
| Voltage - Max | 6V | Current - Max | 40A |
| Current - Hold (Ih) | 750mA | Current - Trip (It) | 1.5A |
| Maximum Time to Trip | 200ms | Typical Power Dissipation | 600mW |
| Resistance - Initial (Ri) (Min) | 90mΩ | Resistance - Post Trip (R1) (Max) | 385mΩ |
| Operating Temperature | -40℃~85℃ |
