Description:
| Manufacturer | RUILON(Shenzhen Ruilongyuan Elec) | Manufacturer's Part # | RL60-375 |
|---|---|---|---|
| Categories | Circuit Protection | Sub-Categories | PTC Resettable Fuses |
| Series | Material Type | - | |
| Voltage - Max | 60V | Current - Max | 40A |
| Current - Hold (Ih) | 3.75A | Current - Trip (It) | 7.5A |
| Maximum Time to Trip | 24s | Typical Power Dissipation | 3.2W |
| Resistance - Initial (Ri) (Min) | 30mΩ | Resistance - Post Trip (R1) (Max) | 60mΩ |
| Operating Temperature | -40℃~85℃ |
