Description:
| Manufacturer | Littelfuse | Manufacturer's Part # | 1.5SMC30CA |
|---|---|---|---|
| Categories | Circuit Protection | Sub-Categories | TVS - Diodes |
| Series | 1.5SMC | Part Status | Active |
| Type | Zener | Unidirectional Channels | - |
| Bidirectional Channels | 1 | Voltage - Reverse Standoff (Typ) | 25.6V |
| Voltage - Breakdown (Min) | 28.5V | Voltage - Clamping (Max) @ Ipp | 41.4V |
| Current - Peak Pulse (10/1000µs) | 36.7A | Power - Peak Pulse | 1500W (1.5kW) |
| Power Line Protection | No | Applications | General Purpose |
| Capacitance @ Frequency | - | Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount | Package / Case | DO-214AB, SMC |
| Supplier Device Package | DO-214AB (SMCJ) |
