Description:
| Manufacturer | Panasonic | Manufacturer's Part # | EVQ-PAE05R |
|---|---|---|---|
| Categories | Switches | Sub-Categories | Tactile Switches |
| Series | EVQPA | Part Status | Last Time Buy |
| Circuit | SPST-NO | Switch Function | Off-Mom |
| Contact Rating @ Voltage | 0.02A @ 15VDC | Actuator Type | Standard |
| Mounting Type | Through Hole | Actuator Height off PCB, Vertical | 5.00mm |
| Actuator Length, Right Angle | - | Actuator Orientation | Top Actuated |
| Termination Style | PC Pin | Outline | 6.00mm x 6.00mm |
| Illumination | Non-Illuminated | Illumination Type, Color | - |
| Illumination Voltage (Nominal) | - | Operating Force | 160gf |
| Ingress Protection | - | Features | - |
| Operating Temperature | -20°C ~ 70°C |
