Description:
| Manufacturer | Shenzhen JDT Fuse | Manufacturer's Part # | JFC1206-0250FS |
|---|---|---|---|
| Categories | Circuit Protection | Sub-Categories | Fuses |
| Series | Product | Chip Fuse | |
| Fuse Type | Fast Blow | Current Rating | 250mA |
| Rated Voltage(AC) | - | Rated Voltage(DC) | 24V/32V/63V/72V |
| Nominal Cold Resistance | 3.608Ω | Nominal Voltage Drop | 1.407V |
| Breaking Capacity @ Rated Voltage | 50A | Melting I²t | 0.00040 |
| Operating Temperature | -55°C ~ 125°C |
