Description:
| Manufacturer | Texas Instruments | Manufacturer's Part # | TLC27L2CD |
|---|---|---|---|
| Categories | Integrated Circuits (ICs) | Sub-Categories | Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps |
| Series | LinCMOS™ | Part Status | Active |
| Amplifier Type | General Purpose | Number of Circuits | 2 |
| Output Type | - | Slew Rate | 0.05V/µs |
| Gain Bandwidth Product | 110kHz | -3db Bandwidth | - |
| Current - Input Bias | 0.7pA | Voltage - Input Offset | 1.1mV |
| Current - Supply | 29µA | Current - Output / Channel | 30mA |
| Voltage - Supply, Single/Dual (±) | 3V ~ 16V, ±1.5V ~ 8V | Operating Temperature | 0°C ~ 70°C |
| Mounting Type | Surface Mount | Package / Case | 8-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 8-SOIC |
