Description:
| Manufacturer | Laird | Manufacturer's Part # | CM2021Y330R-10 |
|---|---|---|---|
| Categories | Filters | Sub-Categories | Common Mode Chokes |
| Series | CM | Part Status | Active |
| Filter Type | Power Line | Number of Lines | 2 |
| Impedance @ Frequency | 33 Ohms @ 100MHz | Inductance @ Frequency | - |
| Current Rating (Max) | 15A | DC Resistance (DCR) (Max) | 0.75 mOhm |
| Voltage Rating - DC | 280V | Voltage Rating - AC | - |
| Operating Temperature | -40°C ~ 125°C | Ratings | - |
| Approvals | - | Features | - |
| Mounting Type | Surface Mount | Size / Dimension | 0.231" L x 0.220" W (5.88mm x 5.60mm) |
| Height (Max) | 0.150" (3.80mm) | Package / Case | 2322 (5956 Metric), 4 Lead |
