Part No.：STTH5L06B-TR
Category：Semiconductor
Manufacturer：STMicroelectronics
Date Code：
Package Type： TO-252-3
Quantity：100000
Click：11
Update Time：2022-06-11 10:11:18
Description:
| Manufacturer | STMicroelectronics | Manufacturer's Part # | STTH5L06B-TR |
|---|---|---|---|
| Categories | Discrete Semiconductor Products | Sub-Categories | Diodes - Rectifiers - Single |
| Series | - | Part Status | Active |
| Diode Type | Standard | Voltage - DC Reverse (Vr) (Max) | 600V |
| Current - Average Rectified (Io) | 5A | Voltage - Forward (Vf) (Max) @ If | 1.3V @ 5A |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) | Reverse Recovery Time (trr) | 95ns |
| Current - Reverse Leakage @ Vr | 5µA @ 600V | Capacitance @ Vr, F | - |
| Mounting Type | Surface Mount | Package / Case | TO-252-3, DPak (2 Leads + Tab), SC-63 |
| Supplier Device Package | DPAK | Operating Temperature - Junction | 175°C (Max) |
