Part No.：HCPL-3120-000E
Category：Isolator
Manufacturer：Broadcom Limited
Date Code：
Package Type：8-DIP
Quantity：50000
Click：32
Update Time：2022-06-17 14:08:51
Description:
| Manufacturer | Broadcom Limited | Manufacturer's Part # | HCPL-3120-000E |
|---|---|---|---|
| Categories | Isolators | Sub-Categories | Isolators - Gate Drivers |
| Series | - | Part Status | Active |
| Technology | Optical Coupling | Number of Channels | 1 |
| Voltage - Isolation | 3750Vrms | Common Mode Transient Immunity (Min) | 25kV/µs |
| Propagation Delay tpLH / tpHL (Max) | 500ns, 500ns | Pulse Width Distortion (Max) | 300ns |
| Rise / Fall Time (Typ) | 100ns, 100ns | Current - Output High, Low | 2A, 2A |
| Current - Peak Output | 2.5A | Voltage - Forward (Vf) (Typ) | 1.5V |
| Current - DC Forward (If) (Max) | 25mA | Voltage - Supply | 15V ~ 30V |
| Operating Temperature | -40°C ~ 100°C | Mounting Type | Through Hole |
| Package / Case | 8-DIP (0.300", 7.62mm) | Supplier Device Package | 8-DIP |
| Approvals | CSA, UR |
