Part No.：T12S5-7
Category：TVS - Diodes
Manufacturer：Diodes Incorporated
Date Code：
Package Type：SOD523
Quantity：50000
Click：22
Update Time：2022-06-20 11:02:46
Description:
| Manufacturer | Diodes Incorporated | Manufacturer's Part # | T12S5-7 |
|---|---|---|---|
| Categories | Circuit Protection | Sub-Categories | TVS - Diodes |
| Series | - | Part Status | Active |
| Type | Zener | Unidirectional Channels | 1 |
| Bidirectional Channels | - | Voltage - Reverse Standoff (Typ) | 12V |
| Voltage - Breakdown (Min) | 14.1V | Voltage - Clamping (Max) @ Ipp | 28V |
| Current - Peak Pulse (10/1000µs) | 12A (8/20µs) | Power - Peak Pulse | 300W |
| Power Line Protection | No | Applications | General Purpose |
| Capacitance @ Frequency | 60pF @ 1MHz | Operating Temperature | -65°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount | Package / Case | SC-79, SOD-523 |
| Supplier Device Package | SOD-523 |
