Part No.：AB38T-32.768KHZ
Category：Crystals
Manufacturer：Abracon LLC
Date Code：
Package Type： DT-38
Quantity：50000
Click：13
Update Time：2022-07-08 10:04:45
Description:
| Manufacturer | Abracon LLC. | Manufacturer's Part # | AB38T-32.768KHZ |
|---|---|---|---|
| Categories | Crystals, Oscillators, Resonators | Sub-Categories | Crystals |
| Series | AB38T | Part Status | Active |
| Type | kHz Crystal (Tuning Fork) | Frequency | 32.768kHz |
| Frequency Stability | - | Frequency Tolerance | ±20ppm |
| Load Capacitance | 12.5pF | ESR (Equivalent Series Resistance) | 30 kOhms |
| Operating Mode | Fundamental | Operating Temperature | -10°C ~ 60°C |
| Ratings | - | Mounting Type | Through Hole |
| Package / Case | Cylindrical Can, Radial | Size / Dimension | 0.126" Dia x 0.330" L (3.20mm x 8.30mm) |
| Height - Seated (Max) | 0.327" (8.30mm) |
