Part No.：VLS4012ET-4R7M
Category：Fixed Inductors
Manufacturer：TDK Corporation
Date Code：
Package Type：-
Quantity：50000
Click：18
Update Time：2022-07-11 13:55:48
Description:
| Manufacturer | TDK Corporation | Manufacturer's Part # | VLS4012ET-4R7M |
|---|---|---|---|
| Categories | Inductors, Coils, Chokes | Sub-Categories | Fixed Inductors |
| Series | VLS | Part Status | Not For New Designs |
| Type | Wirewound | Material - Core | Ferrite |
| Inductance | 4.7µH | Tolerance | ±20% |
| Current Rating | 1.2A | Current - Saturation | 1.2A |
| Shielding | Shielded | DC Resistance (DCR) | 118 mOhm Max |
| Q @ Freq | - | Frequency - Self Resonant | - |
| Ratings | - | Operating Temperature | -40°C ~ 105°C |
| Inductance Frequency - Test | 1MHz | Features | - |
| Mounting Type | Surface Mount | Package / Case | Nonstandard |
| Supplier Device Package | - | Size / Dimension | 0.157" L x 0.157" W (4.00mm x 4.00mm) |
| Height - Seated (Max) | 0.047" (1.20mm) |
