Part No.：RZM001P02T2L
Category： FETS
Manufacturer：ROHM Semiconductor
Date Code：
Package Type：SOT-723
Quantity：50000
Click：43
Update Time：2022-07-15 17:24:51
Description:
| Manufacturer | ROHM Semiconductor | Manufacturer's Part # | RZM001P02T2L |
|---|---|---|---|
| Categories | Discrete Semiconductor Products | Sub-Categories | Transistors - FETs, MOSFETs - Single |
| Series | - | Part Status | Active |
| FET Type | P-Channel | Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 20V | Current - Continuous Drain (Id) @ 25°C | 100mA (Ta) |
| Drive Voltage (Max Rds On, Min Rds On) | 1.2V, 4.5V | Rds On (Max) @ Id, Vgs | 3.8 Ohm @ 100mA, 4.5V |
| Vgs(th) (Max) @ Id | 1V @ 100µA | Gate Charge (Qg) (Max) @ Vgs | - |
| Vgs (Max) | ±10V | Input Capacitance (Ciss) (Max) @ Vds | 15pF @ 10V |
| FET Feature | - | Power Dissipation (Max) | 150mW (Ta) |
| Operating Temperature | 150°C (TJ) | Mounting Type | Surface Mount |
| Supplier Device Package | VMT3 | Package / Case | SOT-723 |
