Part No.：CSD15571Q2
Category： FETS
Manufacturer：Texas
Date Code：
Package Type：6-SON
Quantity：50000
Click：11
Update Time：2022-07-18 13:44:36
Description:
| Manufacturer | Texas | Manufacturer's Part # | CSD15571Q2 |
|---|---|---|---|
| Categories | Discrete Semiconductor Products | Sub-Categories | Transistors - FETs, MOSFETs - Single |
| Series | NexFET™ | Part Status | Active |
| FET Type | N-Channel | Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 20V | Current - Continuous Drain (Id) @ 25°C | 22A (Ta) |
| Drive Voltage (Max Rds On, Min Rds On) | 4.5V, 10V | Rds On (Max) @ Id, Vgs | 15 mOhm @ 5A, 10V |
| Vgs(th) (Max) @ Id | 1.9V @ 250µA | Gate Charge (Qg) (Max) @ Vgs | 6.7nC @ 10V |
| Vgs (Max) | ±20V | Input Capacitance (Ciss) (Max) @ Vds | 419pF @ 10V |
| FET Feature | - | Power Dissipation (Max) | 2.5W (Ta) |
| Operating Temperature | -55°C ~ 150°C (TJ) | Mounting Type | Surface Mount |
| Supplier Device Package | 6-SON (2x2) | Package / Case | 6-WDFN Exposed Pad |
