Part No.：STPS20H100CG-TR
Category：Rectifier
Manufacturer：STMicroelectronics
Date Code：
Package Type：D2PAK
Quantity：50000
Click：19
Update Time：2022-08-01 16:53:40
Description:
| Manufacturer | STMicroelectronics | Manufacturer's Part # | STPS20H100CG-TR |
|---|---|---|---|
| Categories | Discrete Semiconductor Products | Sub-Categories | Diodes - Rectifiers - Arrays |
| Series | - | Part Status | Active |
| Diode Configuration | 1 Pair Common Cathode | Diode Type | Schottky |
| Voltage - DC Reverse (Vr) (Max) | 100V | Current - Average Rectified (Io) (per Diode) | 10A |
| Voltage - Forward (Vf) (Max) @ If | 770mV @ 10A | Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Reverse Recovery Time (trr) | - | Current - Reverse Leakage @ Vr | 4.5µA @ 100V |
| Operating Temperature - Junction | 175°C (Max) | Mounting Type | Surface Mount |
| Package / Case | TO-263-3, D²Pak (2 Leads + Tab), TO-263AB | Supplier Device Package | D2PAK |
