Part No.：SI8235BD-D-ISR
Category：Isolator
Manufacturer：Silicon Labs
Date Code：
Package Type：16SOIC
Quantity：50000
Click：10
Update Time：2022-08-05 11:07:32
Description:
| Manufacturer | Silicon Labs | Manufacturer's Part # | SI8235BD-D-ISR |
|---|---|---|---|
| Categories | Isolators | Sub-Categories | Isolators - Gate Drivers |
| Series | Automotive, AEC-Q100 | Part Status | Active |
| Technology | Capacitive Coupling | Number of Channels | 2 |
| Voltage - Isolation | 5000Vrms | Common Mode Transient Immunity (Min) | 20kV/µs |
| Propagation Delay tpLH / tpHL (Max) | 60ns, 60ns | Pulse Width Distortion (Max) | 5.6ns |
| Rise / Fall Time (Typ) | 12ns, 12ns (Max) | Current - Output High, Low | 2A, 4A |
| Current - Peak Output | 4A | Voltage - Forward (Vf) (Typ) | - |
| Current - DC Forward (If) (Max) | - | Voltage - Supply | 9.4V ~ 24V |
| Operating Temperature | -40°C ~ 125°C | Mounting Type | Surface Mount |
| Package / Case | 16-SOIC (0.295", 7.50mm Width) | Supplier Device Package | 16-SOIC |
| Approvals | CQC, CSA, UR, VDE |
