Metallographic microscope improved the testing system of electronic components,helping to identify the true and false electronic components

Issue Time：2022-10-14 16:57:01Author：ChipsmallSource：Chipsmall LimitedClick：266

On October 10,Chipsmall introduced a batch of high-performance metallographic microscopes to improve the product testing system and strictly control the quality. It meets the current efficient, high accuracy and flexible production and testing need of large batch, multi-variety electronic components, and ensures the availability, applicability and good use of electronic components.

Electronic components are important precision parts in electronic products. With the development of the industry and the continuous innovation of microelectronics technology, its varieties are increasingly rich, the size and appearance and other aspects are becoming more and more complex, and traditional binocular microscopes are also constantly facing challenges. The testing efficiency of traditional manual visual inspection method is low, and this method is susceptible to the influence of personal subjective factors, causing phenomena that false detection, leak detection and so on. Therefore, with the help of high-performance metallographic microscope, the status quo will be changed.

The metallographic microscope introduced this time is a high-tech product developed by perfectly combining optical microscope technology, photoelectric conversion technology and computer image processing technology, which can easily observe metallographic images on computers. It has a coaxial light source, which can reflect the light source into the objective lens under a greater magnification, and more accurately test the defects such as the appearance of electronic components. At the same time,  360 °all-round inspection of the labels, packaging details and product appearance of electronic components and so on will be carried out in strict reference to industry inspection standards, preventing fake and refurbished productions from flowing to customers.

In addition, the device is equipped with a light source status display screen, which can realize the functions of taking photos,recording, replaying, localizing, magnifying, ruler displaying and other functions with one click, and easily obtain clearer images of electronic components. The carrier table is equipped with a coaxial displacement handwheel for precise control, which can precisely control the steady movement of the carrier table in X and Y directions to maintain control of the sample position, magnification or observation module.

Electronic component testing is the early cornerstone of the production chain, which is the quality basis in the quality control, and the foundation determines the superstructure. In the future,Chipsmall will continue to expand investment, establish a higher standard of quality control system, and empower the upstream and downstream of the electronic component industry chain, believing that our persistence and strict quality control management can make the supply chain more secure and reliable.
