Part No.：IRM-15-24
Category：Power Supplies
Manufacturer：MEAN WELL
Date Code：
Package Type：4-DIP Module
Quantity：50000
Click：55
Update Time：2022-06-02 11:30:46
Description:
| Manufacturer | MEAN WELL | Manufacturer's Part # | IRM-15-24 |
|---|---|---|---|
| Categories | Power Supplies - Board Mount | Sub-Categories | AC DC Converters |
| Series | IRM-15 (15W) | Part Status | Active |
| Type | Enclosed | Number of Outputs | 1 |
| Voltage - Input | 85 ~ 264 VAC, 120 ~ 370 VDC | Voltage - Output 1 | 24V |
| Voltage - Output 2 | - | Voltage - Output 3 | - |
| Voltage - Output 4 | - | Current - Output (Max) | 630mA |
| Power (Watts) | 15W | Applications | ITE (Commercial) |
| Features | DC Input Capable, Universal Input | Operating Temperature | -30°C ~ 70°C (With Derating) |
| Efficiency | 83% | Mounting Type | Through Hole |
| Package / Case | 4-DIP Module | Size / Dimension | 2.06" L x 1.07" W x 0.94" H (52.4mm x 27.2mm x 24.0mm) |
