Part No.：39212500000
Category：Fuse
Manufacturer：Littelfuse
Date Code：
Package Type：-
Quantity：50000
Click：1
Update Time：2022-06-16 15:10:54
Description:
| Manufacturer | Littelfuse | Manufacturer's Part # | 39212500000 |
|---|---|---|---|
| Categories | Circuit Protection | Sub-Categories | Fuses |
| Series | TE5® 392 | Part Status | Active |
| Fuse Type | Board Mount (Cartridge Style Excluded) | Current Rating | 2.5A |
| Voltage Rating - AC | 250V | Voltage Rating - DC | - |
| Response Time | Slow Blow | Package / Case | Radial, Box |
| Mounting Type | Through Hole | Breaking Capacity @ Rated Voltage | 25A |
| Melting I²t | 32 | Approvals | CQC, cULus, KC, PSE/JET, SEMKO, VDE |
| Operating Temperature | -40°C ~ 125°C | Color | - |
| Size / Dimension | 0.335" L x 0.157" W x 0.315" H (8.50mm x 4.00mm x 8.00mm) |
