Description:
| Manufacturer | Bourns | Manufacturer's Part # | SRF0905-100Y |
|---|---|---|---|
| Categories | Filters | Sub-Categories | Common Mode Chokes |
| Series | SRF0905 | Part Status | Active |
| Filter Type | Signal Line | Number of Lines | 2 |
| Impedance @ Frequency | 200 Ohms @ 20MHz | Inductance @ Frequency | 10µH @ 1kHz |
| Current Rating (Max) | 1.6A | DC Resistance (DCR) (Max) | 80 mOhm |
| Voltage Rating - DC | 80V | Voltage Rating - AC | - |
| Operating Temperature | -40°C ~ 105°C | Ratings | - |
| Approvals | - | Features | - |
| Mounting Type | Surface Mount | Size / Dimension | 0.362" L x 0.236" W (9.20mm x 6.00mm) |
| Height (Max) | 0.209" (5.30mm) | Package / Case | Horizontal, 4 PC Pad |
