Part No.：IRGP30B120KD-E
Category：Semiconductor
Manufacturer：Infineon Technologies
Date Code：
Package Type：TO247AD
Quantity：50000
Click：21
Update Time：2022-06-02 11:18:23
Description:
| Manufacturer | Infineon Technologies | Manufacturer's Part # | IRGP30B120KD-EP |
|---|---|---|---|
| Categories | Discrete Semiconductor Products | Sub-Categories | Transistors - IGBTs - Single |
| Series | - | Part Status | Not For New Designs |
| IGBT Type | NPT | Voltage - Collector Emitter Breakdown (Max) | 1200V |
| Current - Collector (Ic) (Max) | 60A | Current - Collector Pulsed (Icm) | 120A |
| Vce(on) (Max) @ Vge, Ic | 4V @ 15V, 60A | Power - Max | 300W |
| Switching Energy | 1.07mJ (on), 1.49mJ (off) | Input Type | Standard |
| Gate Charge | 169nC | Td (on/off) @ 25°C | - |
| Test Condition | 600V, 25A, 5 Ohm, 15V | Reverse Recovery Time (trr) | 300ns |
| Operating Temperature | -55°C ~ 150°C (TJ) | Mounting Type | Through Hole |
| Package / Case | TO-247-3 | Supplier Device Package | TO-247AD |
