Part No.：7447715101
Category：Fixed Inductors
Manufacturer：Wurth Electronics
Date Code：
Package Type：Nonstandard
Quantity：50000
Click：12
Update Time：2022-06-11 11:02:30
Description:
| Manufacturer | Wurth Electronics | Manufacturer's Part # | 7447715101 |
|---|---|---|---|
| Categories | Inductors, Coils, Chokes | Sub-Categories | Fixed Inductors |
| Series | WE-PD | Part Status | Active |
| Type | Wirewound | Material - Core | Ferrite |
| Inductance | 100µH | Tolerance | ±20% |
| Current Rating | 1.3A | Current - Saturation | 1.4A |
| Shielding | Shielded | DC Resistance (DCR) | 270 mOhm Max |
| Q @ Freq | - | Frequency - Self Resonant | 6.9MHz |
| Ratings | AEC-Q200 | Operating Temperature | -40°C ~ 125°C |
| Inductance Frequency - Test | 1kHz | Features | - |
| Mounting Type | Surface Mount | Package / Case | Nonstandard |
| Supplier Device Package | - | Size / Dimension | 0.472" L x 0.472" W (12.00mm x 12.00mm) |
| Height - Seated (Max) | 0.177" (4.50mm) |
